Self Aligning Tapered Roller Bearing

1.Product Introduction: It can compensate for ±2° installation deviation and avoid uneven load on the rollers.
2.Structure Type: The inner ring has a tapered raceway, the outer ring has a spherical raceway, with a single - row of rollers + cage, and it is open - type.
3.Size Range: Inner diameter 20 - 500mm, outer diameter 47 - 1000mm, width 14 - 200mm.
4.Material: Inner ring/Outer ring/Rollers: GCr15/GCr15SiMn/20Cr2Ni4A, cage: stamped steel / brass.
5.Precision: P0/P6 level.
6.Application Fields: Agricultural machinery suspension systems, heavy - truck balance shafts, mining machinery.
7.Key Inspection Items: Self - aligning angle, taper surface fitting degree, radial load - bearing capacity.

Product Description

Self Aligning Tapered Roller Bearings Built for Extreme Industrial Demands

30+ Years Specializing in Heavy-Load Solutions – Custom Designs Delivered in 15-20 Days

When your machinery faces harsh conditions like shaft misalignment, heavy shock loads, or extreme temperatures, Self Aligning Tapered Roller Bearings offer unmatched durability. These bearings automatically adjust to ±2° installation deviations, preventing uneven roller wear while handling combined radial and axial loads. At LUOYANG INNO BEARING, we’ve refined these solutions over three decades for industries where failure isn’t an option.

Key Advantages

  • Precision Alignment: Compensates for misalignment caused by ground settlement or vibration, reducing maintenance downtime by 40%.
  • Industry-Tailored: Metallurgy-grade bearings withstand 500°C continuous operation, while mining-grade units feature tungsten carbide coatings.
  • Rapid Customization: Bespoke bearing designs delivered in 15–20 days via modular assembly.

Technical Specifications

Parameter Customization Range
Bore Diameter 20mm to 3000mm
Contact Angle 10° (low friction) to 30° (high axial load)
Material Options GCr15, M50 Steel, Ceramic Hybrids
Sealing Triple-lip, Labyrinth, or PTFE-coated

Quality Assurance

Every Self Aligning Tapered Roller Bearing undergoes:

  • Material Purity: Spectrometer analysis ensures <0.002% sulfur content.
  • Thermal Cycling: 50+ cycles between -40°C and 500°C.
  • Performance Validation: 100 million cycles at 120% rated capacity and <35dB noise certification.

Technical Support

We provide installation alignment guides, laser-assisted mounting protocols, and IoT integration kits for real-time load monitoring via vibration/temperature sensors.

FAQs

Q: How do your bearings handle 500°C temperatures in steel mills?
A: Our metallurgy-grade bearings use diffusion-bonded graphite cages and high-purity M50 steel, maintaining dimensional stability through quenching cycles.

Q: Can you customize the contact angle for specific load requirements?
A: Yes – submit your radial/axial load ratios, and we'll CAD-optimize the roller geometry within 72 hours.

Q: How does your IoT monitoring reduce crusher downtime?
A: Our vibration threshold alerts detect abnormal loading 6-8 weeks before bearing failure.
