Double Row Angular Contact Ball Bearing

1.Product Introduction: With a double-row steel ball and double contact angle design, capable of bearing bidirectional combined loads, without the need for additional paired bearings, suitable for bidirectional precision transmission scenarios.
2.Structure Type: Inner ring + outer ring (with double angular contact raceways) + double-row steel balls + brass cage. An isolation ring is set in the middle to prevent steel ball collisions.
3.Size Range: Inner diameter: 20 - 500mm, outer diameter: 47 - 800mm, width: 20 - 180mm.
4.Material: Inner ring / outer ring / isolation ring: GCr15/GCR15SIMN, rolling elements (steel balls): GCr15/GCR15SIMN, cage: brass.
5.Accuracy: Conventional P0 grade, precision models are of P6/P5/P4 grades.
6.Application Fields: Machine tool spindles (bidirectional positioning), large motors, transmission ends of port cranes, precision reducers.
7.Key Inspection Items: Consistency of double-row steel ball clearance (deviation ≤ 0.002mm), accuracy of bidirectional contact angles, radial runout, running stability.

Product Description

Double Row Angular Contact Ball Bearings for Extreme Load & Precision Scenarios

When your equipment demands bidirectional load handling and space-efficient precision, double row angular contact ball bearings deliver unmatched performance. Designed with two rows of balls and optimized contact angles, these bearings eliminate the need for paired arrangements while handling combined axial and radial loads. At LUOYANG INNO BEARING, we create ball bearing solutions that thrive in metallurgy, wind energy, and robotics.

Technical Specifications

Parameter Standard Range Custom Capacity
Inner Diameter 20-500mm Up to 5000mm custom bearing options
Contact Angle & Cages 25°/30°/40°; Brass cages Any angle ±0.5°; PEEK/Stainless steel bearing cages
Load Handling Radial up to 380kN / Axial up to 210kN 2.3x higher moment stiffness for heavy-duty angular contact bearings
Precision & Materials Standard to P4/P2 precision GCr15 steel or Si3N4 ceramic hybrid ball bearings

Key Advantages

  • Bidirectional Load Mastery: Optimized raceway geometries handle high radial and axial loads in compact double row angular contact ball bearings.
  • Industry Tailored: DNV GL-certified offshore units, noise-optimized medical bearings (<25dB), and 500°C steel mill variants.
  • Rapid Customization: Non-standard double row ball bearings from 10mm to 5000mm ID delivered in 15-20 days.

Built for Demanding Applications

  • Wind Turbine Yaw/Pitch Systems: Triple-labyrinth seals with IP69K protection for long-life offshore angular contact bearings.
  • Automotive Robotic Arms: P2 ultra-precision grinding for smooth motion in robotic joint ball bearings.
  • High-Speed Spindles: Preloaded configurations for high RPM operations in machining center spindles.

Quality Assurance & Logistics

Every double row angular contact ball bearing undergoes vacuum-degassed steel testing, 3D clearance consistency grinding (≤0.002mm), and 200-hour accelerated lifespan simulations. We offer 48-hour dispatch for standard stock items.

FAQs

Q: Can you match legacy double row angular contact ball bearing dimensions?
A: Yes! Share your drawings or samples, and we will reverse-engineer custom replacement bearings with modern materials.

Q: How do you prevent lubricant leakage in vertical bearing installations?
A: We modify cage designs and integrate specialized PTFE seals for high-tilt angular contact ball bearings.

Q: What is the minimum order quantity for custom double row ball bearing designs?
A: MOQ starts at 1 piece for prototyping, with volume discounts available for bulk orders.

Contact Us

Ready to Optimize Your Bearing Performance with a Double Row Angular Contact Ball Bearing?

Contact our engineering team to receive load capacity calculations, material recommendations, CAD models, or installation simulations within 2 working hours.
