Double Row Full Complement Cylindrical Roller Bearings

1.Product Introduction: Double-row full-complement rollers, with load capacity 1.3-1.5 times that of ordinary double-row bearings, suitable for low-speed and ultra-heavy load scenarios.
2.Structure Type: Inner ring/Outer ring with double ribs, double-row full-complement rollers (no cage), intermediate spacer ring, open type.
3.Dimension Range: Inner diameter: 50-500mm, Outer diameter: 100-800mm, Width: 40-150mm
4.Material: Inner ring/Outer ring/Spacer ring/Rollers: GCr15/GCr15SiMn/20Cr2Ni4A; Cage: Stamped steel/brass; Spacer blocks: Engineering plastic
5.Accuracy: Class P0/P6, Class P5 for special requirements
6.Application Fields: Mining machinery spindles, heavy crane wheels, rolling mill work rolls, port heavy-duty equipment
7.Key Inspection Items: Assembly density of double-row rollers, radial load capacity, spacer ring strength

Product Description

Double Row Full Complement Cylindrical Roller Bearings

When heavy machinery faces extreme loads, temperatures, or harsh environments, double row full complement cylindrical roller bearings deliver unmatched reliability. Engineered without cages to maximize roller density, these bearings offer 30% higher radial load capacity than standard designs, making them ideal for mining equipment, port cranes, and medical imaging systems. With 30+ years of expertise, LUOYANG INNO BEARING CO., LTD specializes in customizing roller bearing solutions that outperform in the toughest conditions.

Technical Specifications

Parameter Specification
Design Double-row rollers, full complement (no cage), intermediate spacer ring
Load Capacity 1.3–1.5x higher radial load capacity than standard double-row bearings
Temperature Range -50°C to +150°C (carburized steel option for high heat)
Materials & Precision GCr15/GCr15SiMn/20Cr2Ni4A bearing steel; ISO P0/P6 (P5 for special applications)

Key Advantages

  • Full Roller Complement: 25% better load distribution for longer bearing service life.
  • Proven Heat Resistance: Carburizing extends roller bearing lifespan in high-temperature environments.
  • Rapid Customization: Non-standard double row full complement cylindrical roller bearings (φ5000mm+) delivered in 25-30 days.

Industry-Proven Applications

  • Heavy Industry & Metallurgy: Withstand 150°C+ temperatures and heavy shock loads in rolling mill bearing setups.
  • Port Machinery: Multi-layer anti-corrosion coatings resist saltwater and absorb high-frequency shocks in crane slewing rings.
  • Medical Imaging: Operate below 35dB noise with zero particle emission in cylindrical roller bearing assemblies for MRI/PET-CT gantries.

Quality & Logistics

Every bearing undergoes 3-stage quality inspections to guarantee 99.9% defect-free performance. We maintain 1,000+ standard roller bearing models in global warehouses for 48-hour shipment.

FAQs

Q: Can you make bearings larger than φ5000mm?
A: Yes! Our modular production system handles custom double row full complement cylindrical roller bearings up to φ5000mm+ with a 25-30 day lead time.

Q: How do you ensure corrosion resistance in port bearing environments?
A: We apply multi-layer anti-corrosion coatings tested to IP67 standards on all external roller bearing surfaces.

Q: What's the minimum order quantity for custom bearing designs?
A: MOQ starts at 10 units for custom designs, while standard bearings ship within 48 hours.
