Cylindrical Roller Thrust Bearings

1.Product Introduction: With cylindrical rollers as the rolling elements, having stronger axial load-bearing capacity than thrust ball bearings, impact-resistant, suitable for medium and heavy axial load scenarios.
2.Structure Type: Shaft washer + housing washer + cylindrical rollers + cage. The rollers are arranged axially, and it has an open structure.
3.Size Range: Inner diameter: 30 - 600mm, outer diameter: 70 - 800mm, height: 20 - 100mm.
4.Material: Shaft washer: GCr15/GCR15SIMN/20Cr2Ni4A, housing washer: GCr15/GCR15SIMN/20Cr2Ni4A, rolling elements (cylindrical rollers): GCr15/GCR15SIMN, cage: steel / brass.
5.Accuracy: Conventional P0/P6 grades, heavy-duty models are of P5 grade.
6.Application Fields: Mining machinery, heavy-duty reducers, port cranes, large motors.
7.Key Inspection Items: Axial load-bearing capacity, parallelism of rollers, flatness of shaft washer and housing washer.

Product Description

High-Performance Cylindrical Roller Thrust Bearings for Extreme Industrial Applications

When your machinery faces relentless axial loads, extreme temperatures, or corrosive environments, cylindrical roller thrust bearings deliver unmatched durability. At LUOYANG INNO BEARING CO., LTD, we engineer these bearings to outperform standard thrust ball bearings in heavy-load scenarios, offering axial load capacities up to 12,000kN and precision tolerances as tight as P4 grade. With 30+ years of expertise, our roller bearing products are trusted in mining, metallurgy, and medical equipment worldwide.

High-Performance Cylindrical Roller Thrust Bearings for Extreme Industrial Applications

When your machinery faces relentless axial loads, extreme temperatures, or corrosive environments, cylindrical roller thrust bearings deliver unmatched durability. At LUOYANG INNO BEARING CO., LTD, we engineer these bearings to outperform standard thrust ball bearings in heavy-load scenarios, offering axial load capacities up to 12,000kN and precision tolerances as tight as P4 grade. With 30+ years of expertise, our roller bearing products are trusted in mining, metallurgy, and medical equipment worldwide.

Industry-Specific Solutions

  • Metallurgy & Mining: High-temperature cylindrical roller thrust bearings endure furnace heat and shock loads in rolling mills.
  • Port Machinery: Corrosion-resistant coatings protect crane slewing ring bearings in saltwater environments.
  • Medical Imaging: Ultra-quiet bearings equipped with nano-polished rollers and ceramic cages for robotic applications.

Quality & Logistics

Every bearing undergoes triple-stage QC checks across materials, production, and finished products. Standard roller bearing models ship within 48 hours, while custom φ3000mm+ designs deliver in 15–20 days.

FAQs

Q: How do your cylindrical roller thrust bearings handle high-temperature environments?
A: Proprietary heat treatment and specialized alloy steel ensure stable performance in elevated bearing applications.

Q: Can you make thrust bearings larger than φ5000mm?
A: Yes! Our modular production system supports custom roller bearing dimensions to meet your specs.

Q: What reduces noise in medical-grade bearings?
A: Ceramic rollers and precision grinding achieve near-silent operation below 35dB.

Contact Us

Ready to Upgrade Your Equipment with Cylindrical Roller Thrust Bearings?

Contact our engineering team to request a custom quote, technical datasheets, or load calculation consultations.
